Overview
The CerAnode™ Expandable Rod Anode (EAR) is a high-performance EMMO™ (Enhanced Mixed-Metal Oxide) anode engineered for impressed current cathodic protection (ICCP) systems requiring flexible deployment and optimized current distribution. Designed for deep, shallow, and irregular anode bed geometries, it delivers consistent current output and long-term durability.
Constructed on a titanium substrate with a ceramic EMMO™ coating, the EAR provides a stable, corrosion-resistant surface for extended service life in aggressive environments. Its expandable, tension-adjustable design enables controlled deployment and uniform current distribution across long runs and variable installation conditions.
Factory-assembled and installation-ready, the CerAnode™ EAR minimizes field handling while ensuring low-resistance electrical connections and reliable system performance in critical infrastructure applications.
Key Features & Benefits
EMMO™ Coating Technology
Arc plasma–sprayed, mixed-metal oxide coating delivers a dense, mechanically bonded surface with significantly enhanced abrasion resistance over conventional MMO systems.
Expandable, Tension-Adjustable Design
Enables flexible deployment and optimized spacing, supporting uniform current distribution across complex or variable anode beds.
Low-Resistance Electrical Connection
Factory-sealed, corrosion-resistant connections ensure efficient current transfer and consistent ICCP performance.
Long-Life Durability
Engineered to resist abrasion, environmental stress, and electrolyte exposure in soil and marine environments.
Versatile Deployment
Suitable for groundbeds, pipelines, subsea systems, and custom cathodic protection designs.
Typical Applications
- Deep and shallow groundbed systems
- Pipeline cathodic protection, including long or irregular runs
- Marine and offshore structures Subsea infrastructure and risers
- Power transmission and utility systems
- Custom ICCP system designs requiring flexible anode configurations
Installation & Accessories
Tension-Ready Deployment
Delivered factory-assembled for rapid installation and controlled expansion in the field.
Low-Resistance Electrical Terminations
Factory-sealed cable connections ensure stable ICCP performance and efficient current transfer.
Optional Anchoring Hardware
Available with tensioning components, ballast systems, and custom anchoring accessories.
Monitoring Compatibility
Integrates with rectifiers, reference electrodes, and cathodic protection monitoring systems.
Customizable System Design
Available in varying lengths, current capacities, cable types, and deployment configurations.
Documentation
- Technical Data SheetDownload 840 KB
Engineered for your application
No two cathodic protection systems are identical. Tell us the current requirement, electrolyte and installation constraints and we will configure the anode around them.
